Magewell Pro Capture HDMI TX
Magewell Pro Capture HDMI TX Front
Magewell Pro Capture HDMI TX Back
Special Order
  • SKU: 64050

Magewell Pro Convert HDMI TX

  • Vendor: Magewell
  • Product Type: Converters

Special Order Item - Lead time of 3 weeks from order

Magewell Pro Convert HDMI TX is a super compact device that will convert your HDMI video signal to the NDI protocol allowing reliability and versatility in your live streaming workflow for your HDMI devices.

The Magewell Pro Convert HDMI TX Plus adopts NewTek’s royalty-free NDI® protocol for encoding and transmission, the Pro Convert family easily and reliably converts HDMI video signals into NDI streams.

These NDI streams will be available to all NDI-compatible software and systems on the same network regardless of physical distance, ensuring high-quality, low-latency, IP-based live production experiences superior to traditional live production solutions.

Magewell Pro Convert HDMI TX

Easy-to-Use With Zero Configuration

Pro Convert devices automatically detect your network and the video input signal format, with no manual network configuration nor source format selection needed. Plug in the cables, and it just works!

Compact and Powerful

Pro Convert HDMI TX features a small size of 100.9mm x 60.2mm and 23.3mm thickness, weighing only 230g.

Find out further info over at Magewell's website.

Pro Convert HDMI TX Specifications
Supported Web Browser Microsoft Internet Explorer 11
Microsoft Edge
Mozilla Firefox version 61 and above
Google Chrome version 49 and above
Apple Safari 11.1 and above
Opera 55.0.2994.44 and above
Supported Software OBS
streamstar SW
Any other NewTek NDI-enabled encoding or streaming software
Input Interfaces HDMI:
DVI-D 1.0
HDMI 1.4
Storage Interface SD Card (functions to be developed)
PTZ + TALLY Control Mini-DIN–8 jack
Screw Mounting Hole 1⁄4–20 mounting hole
Network Interfaces 10/100/1000Mbps Ethernet
IEEE 802.3af PoE
USB Interface USB2.0 Type B
5V/2.1A power supply
Input feature Support input video resolutions at up to 2048x1200
HDMI Specific Features 165MHz HDMI receiver
Adaptive HDMI equalizer support for cables lengths up to 30M
Support for customized EDID
Support for extraction of AVI/Audio InfoFrames
Full colorimetry support
Support up to 2048x1200 4:4:4/4:2:2 60fps input signals
Support 8 input and 2 output IEC60958 audio streams
Support for extraction of audio formation information & channel status data
Support for extraction of video timing information
Support for extraction of 3D format information
Support for Side-by-Side Half, Top-and-Bottom, Frame Packing 3D mode.
NDI® Output Format Support for 4:2:2 8-bit output
Support for up to 2048x2160 120fps
Support for NDI 3.x
Video Processing Features Video processing pipelines with 160 Mpixels/s
Video brightness, contrast, saturation, hue adjustment
Video de-interlacing:
Top field only
Bottom field only
Video aspect ratio conversion:
Auto or manual selection of output aspect ratio
Video color format conversion:
Auto or manual selection of input color format & quantization range
Auto or manual selection of output color format, quantization range & saturation range
Support for RGB, YUV BT.601, YUV BT.709, YUV BT.2020 input color formats
Support for YUV BT.601, YUV BT.709, YUV BT.2020 output color formats
Support for Limited or Full quantization range
Support for Limited, Full & ‘Extended gamut’ saturation range
Video frame rate conversion
Video mirror flip
NDI® Source Name Support for setting the device name shown in the system using Web UI. By default, the device name is ‘Pro Convert’.
Support for setting the source name shown in the system using Web UI. By default, the source name is ‘board-index + serial number’.
Support for setting board-index, from 0 to F, through on-board rotary switch
Firmware Upgrade Support for manual update using Web UI
LED Indicator Status LEDs indicate:
Power supply indicator: on/off
Input signal indicator: locked/unlocked
Form Factor 100.9smm (L) x 60.2mm (W) x 23.3mm (H)
Accessories USB 2.0 A to B Cable
5V/2.1A power adaptor
Mini-DIN–8 (PTZ + TALLY) to RS232 (PTZ) + Mini-DIN–8 (TALLY)
LED matrix panel (optional)
Power Consumption 5V max current: ~1.5A
Max power consumption: ~8W
Working Environment Operating temperature: 0 to 45 deg C
Storage temperature: –20 to 70 deg C
Relative Humidity: 5% to 90% non-condensing
Specifications correct at time of publication
