Description
| Connections | |
|---|---|
| SDI Video Inputs | 1 x Micro BNC |
| SDI Audio Inputs | 16 channels embedded via 12G-SDI |
| SDI Video Outputs | 1 x Micro BNC |
| SDI Audio Outputs | 16 channels embedded via 12G-SDI |
| SDI Rates | 270Mb, 1.5G, 3G, 6G, 12G. |
| HDMI Audio Inputs | 8 channels embedded via HDMI 2.0a |
| HDMI 2.0a Video Inputs | 1 |
| HDMI Audio Outputs | 8 channels embedded via HDMI 2.0a |
| HDMI 2.0a Video Outputs | 1 |
| Remote Control | None |
| Analog Audio Inputs | None, embedded audio only. |
| SD Interface | 1 x UHS-II SD slot. |
| Analog Audio Outputs | 1 x 3.5 mm headphone jack. |
| Built in Speaker | Mono |
| Storage Type | Removable SDXC UHS-II, SDXC UHS-I and SDHC UHS-I SD cards. Supports DS, HS, SDR12, SDR25, DDR50, SDR50 and SDR104 SD cards. |
| Screen Dimensions | 5 inch 1920 x 1080. |
| Screen Brightness | 2500nits |
| Screen Color | P3 wide color gamut |
| Computer Interface | 1 x USB Type-C 3.1 Gen 1 for external drive recording, initial setup, software updates and Video Assist Utility software control. |
| SDI Video Standards | |
| SD Video Standards | 525i59.94 NTSC, 625i50 PAL |
| HD Video Standards | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60 |
| 2K Video Standards | 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| 4K Video Standards | 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 425M, SMPTE 2084 |
| SDI Metadata Support | HD RP188 |
| Audio Sampling | Television standard sample rate of 48 kHz and 24-bit. |
| Video Sampling | 4:2:2 YUV |
| Color Precision | 10-bit |
| Color Space | REC 601, REC 709, REC 2020 |
| HDR Support | HDR10, Hybrid Log Gamma |
| Multiple Rate support | SDI and HDMI switches between 270 Mb/s, 1.5 Gb/s, 3 Gb/s, 6 Gb/s and 12 Gb/s |
| HDMI Video Standards | |
| SD Video Standards | 525i59.94 NTSC, 625i50 PAL |
| HD Video Standards | 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60 |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| 4K Video Standards | 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI |
| HDMI Color Precision | 10-bit |
| HDR Support | HDR10, Hybrid Log Gamma |
| Copy Protection | HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content. |
| Media | |
| Media | 1 x UHS-II SD for Ultra HD, compatible with regular SD for HD recording. USB Type-C 3.1 Gen 1 for external drive recording. |
| Media Type | SDXC UHS-II, SDXC UHS-I and SDHC UHS-I SD cards. |
| Supported Codecs | |
| ProRes 422 HQ, ProRes 422, ProRes 422 LT, DNxHD 220x, DNxHD 145, DNxHD 45, DNxHD 220x MXF, DNxHD 145 MXF, DNxHD 45 MXF, DNxHR HQX MXF, DNxHR HQX, DNxHR SQ, DNxHR LB, DNxHR SQ MXF, DNxHR LB MXF. | |
| Control | |
| Recorder Control | Integrated capacitive touchscreen LCD with Blackmagic OS onscreen controls for settings and navigating menus. |
| External Control | None |
| Software | |
| Software Included | Blackmagic Video Assist Operating System |
| Scopes | |
| Scopes | Waveform, RGB Parade, Vector, Histogram. |
| Viewing Modes | Scopes with picture in picture or picture overlay and opacity control. Waveform and Parade with standard and HDR graticules. |
| Operating Systems | |
| Mac 10.13 High Sierra,Mac 10.14 Mojave or later. Windows 8.1 or Windows 10. |
|
| Power Requirements | |
| Power Supply | 1 x External 12V power supply.Compatible with Sony NP-F style batteries (batteries not included). |
| Physical Specifications | |
| W x L x H | 148mm x 36.5mm 90mm |
| Environmental Specifications | |
| Operating Temperature | 0° to 40° C (32° to 104° F) |
| Relative Humidity | 0% to 90% non-condensing |
| Storage Temperature | -20° to 45° C (-4° to 113° F) |
| What's Included | |
| Blackmagic Video Assist 5” 12G HDR Universal power supply with locking connector and international adapters |
|
| Warranty | |
| 12 Month Limited Manufacturer’s Warranty. | |
| Specifications correct at time of publication | |
