Blackmagic Teranex Mini - HDMI to Optical 12G

Blackmagic DesignSKU: CONVNTRM/MB/HOPT

Price:
Sale price$899.00

Shipping Information

We offer the following shipping options for all items except software downloads and bulky items:

Standard Shipping

  • 4 - 6 working days

Express Shipping

  • 1 - 3 working days (Metro East Coast)
  • Please contact us for a quote for other areas

    Some items may be considered Bulky and therefore attract a greater shipping charge. This is the total shipping charge and is not in addition to our Standard or Express Shipping charges.

    All orders (in stock items) must be placed by 12.30pm AEST/AEDT for same day despatch. Orders placed after 12.30pm, during weekends, holidays or after hours will be processed the following business day.

    We do our best to maintain stock of our most popular items, all other items are normally despatched within a few days however we will advise you if your item is not in stock within 24 hours (excluding weekends and public holidays) and will advise of the approximate delivery time.

    We primarily use Australia Post, TNT, StarTrack Express, Couriers Please, TFM Logistics and Toll Express depending on the delivery location and shipping option chosen.

    Delivery timings are approximate and may differ due to circumstances outside of our control such as flight delays, traffic incidents, extreme weather etc.

    Software downloads that do not require delivery of a physical product do not attract a shipping charge. Serial Numbers will be emailed within 24 hours, turnaround is often within a few hours.

    Description

    Connections HDMI: 1 x HDMI 2.0 type A connector with support for 2160p60.
    Optical Fiber Connection: LC connector, 1310 nanometer wavelength, single mode.
    Optical Fiber Video Output: Automatically matches the SD, HD and 12G-SDI HDMI video input.
    SDI Video Output: Automatically matches the SD, HD and 12G-SDI HDMI video input.
    Analog Audio Input: 2 channels professional balanced analog audio via XLR connectors. Right XLR can be configured for timecode input.
    AES/EBU Audio Input: 4 channels professional 110Ω balanced digital audio via XLR connectors. Right XLR can be configured for Timecode input.
    Multi Rate Support: Automatic switching between SD/HD/2K and 4K.
    Updates and Configuration: USB and Ethernet.
    Re-Clocking: Yes
    Standards SD Format Support: 525/29.97 NTSC, 625/25 PAL.
    HD Format Support: 1280 x 720p50, 1280 x 720p59.94,1280 x 720p60, 1920 x 1080i50,1920 x 1080i59.94, 1920 x 1080i60,1920 x 1080PsF23.98,1920 x 1080PsF24, 1920 x 1080p23.98,1920 x 1080p24, 1920 x 1080p25,1920 x 1080p29.97, 1920 x 1080p30,1920 x 1080p50, 1920 x 1080p59.94,1920 x 1080p60.
    2K Format Support: 2048 x 1080PsF23.98,2048 x 1080PsF24, 2048 x 1080PsF25,2048 x 1080p23.98, 2048 x 1080p24,2048 x 1080p25.
    4K Format Support: 3840 x 2160p23.98, 3840 x 2160p24,3840 x 2160p25, 3840 x 2160p29.97,3840 x 2160p30, 3840 x 2160p50,3840 x 2160p59.94, 3840 x 2160p60,4096 x 2160p23.98, 4096 x 2160p24,4096 x 2160p25, 4096 x 2160p29.97,4096 x 2160p30, 4096 x 2160p50,4096 x 2160p59.94, 4096 x 2160p60.
    SDI Compliance: SMPTE 292M, SMPTE 259M,SMPTE 296M, SMPTE 372M,SMPTE 424M-B, SMPTE 425M,SMPTE 297M for Optical Fiber SDI.
    SDI Video Rates: SDI video connections are switchable between standard definition, high definition level B 3G-SDI, 6G-SDI and 12G-SDI.
    SDI Video Sampling: 4:2:2 and 4:4:4.
    SDI Audio Sampling: Television standard sample rate of 48 kHz and 24-bit.
    SDI Color Precision: YUV 4:2:2 and RGB 4:4:4 in HD, 2K and 4K.
    SDI Color Space: REC 601, REC 709
    HDMI Format Support: 525/29.97 NTSC, 625/25 PAL,1280 x 720p50, 1280 x 720p59.94,1280 x 720p60, 1920 x 1080i50,1920 x 1080i59.94, 1920 x 1080i60,1920 x 1080p23.98, 1920 x 1080p24,1920 x 1080p25, 1920 x 1080p29.97,1920 x 1080p30, 1920 x 1080p50,1920 x 1080p59.94, 1920 x 1080p60,2048 x 1080p23.98, 2048 x 1080p24,2048 x 1080p25, 3840 x 2160p23.98,3840 x 2160p24, 3840 x 2160p25,3840 x 2160p29.97, 3840 x 2160p30,3840 x 2160p50, 3840 x 2160p59.94,3840 x 2160p60, 4096 x 2160p23.98,4096 x 2160p24, 4096 x 2160p25,4096 x 2160p29.97,,4096 x 2160p30,4096 x 2160p50, 4096 x 2160p59.94,4096 x 2160p60.
    HDMI Color Space: REC 601, REC 709
    HDMI Color Precision: YUV 4:2:2 and RGB 4:4:4 in HD, 2K and 4K.
    Copy Protection: HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
    Software Software Control: Mac OS X™ and Windows™ software upgrade via USB or Ethernet.
    Internal Software Upgrade: Via included updater application.
    Settings Control Basic Settings Control: Mini Switches, USB and Ethernet via free software utility.
    Optional Front Panel Control: Front mounted Smart Panel with LCD, rotary knob and six settings button
    Power Requirements Power Supply: 1 x built-in international AC power supply with IEC C14 inlet. IEC Power cable required. 90 - 240V AC Input.
    Power Over Ethernet: Can be powered via 48V DC using PoE+ (power over ethernet).
    Power Consumption: 15 Watts
    Operational Voltage Range: 90 - 240V AC
    Environmental Specifications Operating Temperature: 0°to 40°C (32° to 104°F)
    Storage Temperature: -20° to 60°C (-4° to 140°F)
    Relative Humidity: 0% to 90% non-condensing
    What's Included Teranex Mini - HDMI to Optical 12G
    Software SD Card
    Warranty 3 year Limited Manufacturer’s Warranty.

    *Specifications Correct at time of Publication
