Description
| Specification | XL / XL Ultra |
|---|---|
| Image Sensor (Primary Camera) | 4/3" Sony CMOS 5 K Sensor |
| Lens / Optical Zoom | 20× Optical Zoom Lens (9.8mm ~ 186mm) |
| Video Format | 2160p @ 60/59.94/50/29.97/25 fps 1080p @ 60/59.94/50/30/29.97/25 fps 1080i @ 60/59.94/50 fps 720p @ 60/59.94/50 fps |
| Aperture | f/2.8 ~ f/4.5 |
| Focus | Auto, Manual (PDAF – Phase Detection Auto Focus) |
| Horizontal Field of View (Primary) | 71° (Wide) ~ 4° (Tele) |
| Vertical Field of View (Primary) | 40° (Wide) ~ 2° (Tele) |
| Diagonal Field of View (Primary) | 79° (Wide) ~ 4.5° (Tele) |
| ND Filter | Yes — 1, 1/4, 1/16, 1/64 |
| Optical Low Pass Filter (OLPF) | Yes |
| Image Stabilisation | Digital |
| Digital Zoom | 16× Supersampling |
| Secondary Panoramic Camera Sensor | 1/1.8" Sony CMOS 4 K sensor |
| Secondary Panoramic Camera Focal Length | 4.4mm (fixed) |
| Secondary Horizontal Field of View | 85° |
| Secondary Vertical Field of View | 53° |
| Secondary Diagonal Field of View | 93° |
| Pan / Tilt Rotation | ±170°, -30° ~ +90° |
| Pan Control Speed | 0.05° ~ 120°/s |
| Tilt Control Speed | 0.05° ~ 90°/s |
| Presets | 256 |
| I/O Interfaces (Video Output) | 12G-SDI, 3G SDI ×2, HDMI 2.0, USB-C, 1Gb RJ45, SFP+ Cage (Ethernet) |
| Video Compression Formats | H.264, H.265, SpeedHQ |
| Network Interfaces | 1 × 1GbE Adaptive Ethernet (PoE++), 1 × SFP+ Cage (Ethernet) |
| Encoder Network Protocols | High-Bandwidth NDI®, NDI® HX3, NDI® HX2, SRT, RTSP, RTMP |
| Control Interfaces | 1 Gb Ethernet, SFP+, RS-232 (input & output), RS-422, USB-C (UVC) |
| Control Protocols | VISCA-IP, NDI®, VISCA Serial, Pelco-P, Pelco-D, FreeD Supported |
| Balanced Audio Inputs | XLR ×2 |
| Genlock & Timecode | Supported |
| SD Card Slot | microSD – Recording supported |
| AI Features | Presenter Tracking, Auto-Framing, Zone Tracking, Gesture Control |
| Input Voltage | DC 12V, PoE++ |
| Input Current | 5 A |
| Power Consumption | < 60 W (Max.) |
| Working Temperature | 0 °C ~ +40 °C (32 °F ~ 105 °F) |
| Working Humidity | ~20% ~ 80% (Non-condensing) |
| Dimensions (W × H × D) | 218.6 × 291.6 × 263.3 mm (8.61 × 11.48 × 10.37 in) approx |
| Weight | ≈ 4 kg |
